Usage
This cable is
suitable for rated AC voltage 450/750V or below domestic appliances,
power-operated tools and various portable electric
equipments.
Operating
Characteristics:
A) YZ specification
rated voltage Uo/U IS 300/500V, YC model is 450/750V
B) Max. permissible
operating temperature of the conductor is 65℃
C)W specification cable has the
property of durability and suitable for outdoor touching of greasy dirt.
D)
ZR specification cable has the property of flame-retardant.
Types and Description
TYPES
|
Name
|
Main Usage
|
|
YQ
YQW
|
light type rubber sheathed flexible cable
|
Used for light portable electric equipment and
tools
|
|
YZ
YZW
|
middle type rubber sheathed flexible cable
|
Used for various portable electric equipment and
tools
|
|
YC
YCW
|
heavy type rubber sheathed flexible cable
|
Used for various portable electric equipment
，which can bear larger mechanical force
|
Standard of Product
The cables are
manufactured according to the standard of GB 5013-2008 idt.IEC60245-2004, at the
same time, they are also can be manufactured according to the standard of IEC,
BS, DIN and AEIC.
The bending radius of cable should not
be less than 6 times of the cable’s
OD
