Fluorine Plastic Insulation Heated-Resistant Cable

Index>Special Cable>Fluorine Plastic Insulation Heated-Resistant Cable

1,Flourine plastics insulated heat-resistant corrosion-resistant control cable

Executive standard Q/LB 115.3-2008,based on Standard GB9330-2008
Usage
It is used as signal transmission wire of appliances,meter and automatic control system in petroleum,chemistry,power generating and metallurgy under high,low temp and acid,alkali,oil,water and corrosive circumstances.
Using feature
Operating temp:
F46 fluorine plastics insulated not more than 200 C
F4 fluorine plastics insulated not more than 260 C
F47 fluorine plastics insulated not more than 285 C
For finished cables, the flame retardant meets the requirements of GB 12666-90
Rated voltage :Uo/U 450/750V and below
Mini ambient temp: fixed installation - 60C,not-fixed installation –20C
Mini bending radius: non-armoured cable≥10 times of the cable diameter: armoured cable≥12 times of the cable diameter

2, Flourine plastics insulated heat-resistant corrosion-resistant power cable

Executive standard Q/LB 005.2-2006
Usage
It is used as transmitting electricity and power distribution cable high-temperature in steel ,petroleum,chemistry,power generating and metallurgy under high,low temp and acid,alkali,oil,water and corrosive circumstances voltage up to 0.6/1KV AC.
Using feature
Operating temp:
F46 fluorine plastics insulated not more than 200 C
F4 fluorine plastics insulated not more than 260 C
F47 fluorine plastics insulated not more than 285 C
For finished cables, the flame retardant meets the requirements of GB 12666-90
Rated voltage :Uo/U 0.6/1KV
ambient temperature of installing cable ≥0 C
Mini bending radius is 2 times of the cable diameter while test bending

3, Flourine plastics insulated heat-resistant installation wire

Executive standard Q/LB 005.3-2006
Usage
It is used as transmitting electricity and power distribution heat-resistance installation cable of appliance under high,low temp and acid,alkali,oil,water and corrosive circumstances voltage up to 250V AC.
Using feature
Rated voltage :Uo/U 250V
Long-term working temp ≤200C
